Roof Post (Trapezoidal)

Roof Post (Trapezoidal)

Roof Post is a budget friendly post for solar panels covered roofs which is placed on both
ends & at intervals as intermediates of the system which form as a anchor point for wire rope running across
the system. The roof post are made from Stainless Steel 304 material that ensure reliability to withstand
harshest environment.

Roof Post is designed to be fixed on Trapezoidal/ Standing seam roof top at the ends and intermediate sides of a Horizontal Lifeline installed on the roof
The material of construction of lifeline components like cable extremity, shock absorber, tensioner, intermediate bracket, corner piece, wire rope, etc. Remains SS316
The slots in the base plate makes the post adjustable and allows it to be installed on roof sheets of
different pitch/rib and seam distance
For Trapezoidal roof : Minimum adjustable opening 225 mm and Maximum adjustable opening 400 mm
For Standing Seam : Minimum adjustable opening 220 mm and Maximum adjustable opening 700 mm.
